Discussion on the efficiency and safety of refrigeration technology

Cold to cold storage energy saving is import-ant influencing factors,energy saving refrig-erator door:

● The speed of opening and closing;sealing property;
● The size of a single opening and closing;
● The moisture absorption property of the material ofthe cold storage door;
● The efficiency and safety of human/material passing.

Electric sliding door refrigerator specifications

Safety	Economical
①Permanent light transmission performance ②Persistent flexibility and elasticity, non-toxic	①Economic performance test is energy saving ②High cost performance, high durability, easy to clean ③Damaged parts can be replaced and recycled
High efficiency	Strong
①Quick installation, efficient original packaging ②Sound insulation, prevent solid ingress	①High impact and tear strength ②Chemical and fire resistant ③High UV resistance

*Special features：

Selected additives ensure that the flexible PVC of ATOF is also suitable for special requirements, such as: insect and fly protection, anti-collision, high and low temperature resistance, energy saving, ultraviolet or infrared filtering and other special functions.

The flexible PVC door leaf is supported by a metal half frame and is automatically closed by a torsion spring

Electric sliding door refrigerator specifications

PVC Thickness	7.0mm cannot be spliced or superimposed
PVC Brand	France-ITOEFL
Door material	Polyvinyl chloride (flexible PVC)
Anti-collision layer	Double-layer imported PE material
Low temperature resistance	Use within -40℃
Door frame material	Aluminum alloy / stainless steel
Sub-frame model and material	50*100mm galvanized square tube or 304 stainless steel square tube
Sealing and waterproofing tape	Neoprene
Door frame surface treatment	Acid sand oxidation
Door frame thickness	5.0mm
Hardware Material	Stainless steel 304
Torsion Spring	Imported piano wire
